Troubleshooting Guide
ELECTRICAL SYSTEM BLOCK DIAGRAM
Lift and Extend (Unload) Functions
Jog Up
Ramp out motor and stop
6506-109-005 REV F
Press Extend (+) Button
Open A-Valve
Yes
Top Hall Effects
Sensor Detected?
No
Ramp in motor (Up)
Run motor at max speed
Yes
Top Hall Effects
Sensor Detected?
No
