USING THE OPTIONAL KICKSTAND FOR DIALYSIS SCALE

The kickstand is intended for weighing patients on a scale.
Note:
• The optional kickstand assembly is configured for an X-frame cot retention system only.
• The optional kickstand (6085-102-000) is not compatible with the optional base storage net (6500-160-000).
WARNING
• Stryker recommends a two person operation when using the kickstand.
• Make sure that the patient weight is centered on the cot before using the kickstand.
• Engage the kickstand with your foot only.
• Lower cot height prior to engaging kickstand for increased stability.
• Make sure that the kickstand remains in the retracted position and does not engage during transport.
• Do not use the kickstand as a brake.
• Do not engage kickstand on a sloped surface.
To use the kickstand:
1. Operator 1 engages the kickstand with their foot as shown in Figure 62.
2. Operator 2 lifts the foot end of the cot at a height sufficient to actuate the kickstand.
3. Both operators must make sure that the kickstand is in the forward locked position as shown in Figure 63.
Figure 62
To release the kickstand:
1. Operator 1 lifts the foot end of the cot until both wheels
are off of the floor.
2. Operator 2 rolls the cot slightly forward to make sure
that the kickstand retracts on its own as shown in
Figure 64.
www.stryker.com
Operation Guide
6506-109-005 REV F
Figure 63
Figure 64
