ADJUSTING THE FOOTREST

English
The footrest is adjustable to elevate the patient's legs (see Figure 55).
To raise the footrest, lift the footrest frame (A) as high as possible. The support bracket engages automatically when
released.
To lower the footrest, lift the footrest frame (A) and while holding the frame, lift up on the release handle (B) until the
bracket disengages. Carefully lower the footrest until flat.
A
B
Foot End
Figure 55
