INSTALLING THE HEAD END STORAGE FLAT

English
WARNING
When the optional head end storage flat is being used, ensure that it does not interfere with the operation of the
retractable head section, safety bar and safety hook. Injury to the patient or operator could result.
To install the optional head end storage flat (see Figure 92):
1. Install the Velcro
2. Buckle the restraint straps (B) around the outer rails of the retractable head section.
CAUTION
The weight of the equipment in the head end storage flat (if equipped) must not exceed 40 lb (18 kg).

USING THE TRANSFER FLAT

When transferring larger patients, use of the Transfer Flat (6005-001-001) is recommended.
Return To Table of Contents
1-76
Operation Guide
® straps (A) near the pneumatic cylinder and around the cross bar of the retractable head section.
B
Cross Bar
A
A
V-Tube
Figure 92
6506-109-005 REV F
B
