OPERATING THE OPTIONAL STEER-LOCK

English
To activate steer-lock from the cot foot or head end:
• From the cot foot end, press the red (lock) side of the foot pedal as shown in Figure 58 or from the cot head end,
press down on either red pedal as shown in Figure 59.
• Rotate the cot until at least one head end caster is locked.
To deactivate steer-lock from the cot foot or head end:
• From the cot foot end, press the green (unlock) side of the foot pedal as shown in Figure 60 or from the cot head
end, lift up on either red pedal at the head end as shown in Figure 61.
Return To Table of Contents
1-56
Operation Guide
Figure 58
Figure 60
6506-109-005 REV F
Figure 59
Figure 61
