LOADING THE COT INTO A VEHICLE WITH TWO OPERATORS - POWERED METHOD (CONTINUED)
English
8. Load the cot either from the foot end or with one operator at the foot end and one on the side:
With both operators at the foot end (preferred method):
• Both Operators − Grasp the cot frame at the foot end (Figure 23).
• Operator 1 − Press the retract (–) button until the undercarriage of the cot retracts fully (Figure 24).
With one operator at the foot end and one on the side:
• Operator 1 − Grasp the cot frame at the foot end and press the retract (–) button (Figure 25) until the
undercarriage of the cot retracts fully (Figure 25).
• Operator 2 − Securely grasp the cot outer rail to stabilize the cot during retraction.
9. Both Operators − Push the cot into the patient compartment as shown in Figure 24 or Figure 26 until the cot
engages the cot fastener (not included).
WARNING
When using a cot fastener, do not load the cot into the vehicle with the head section retracted. Loading the cot with the
head section retracted may cause the product to tip or not engage properly in the cot fastener, possibly causing injury
to the patient or operator and/or damage to the cot.
Return To Table of Contents
1-38
Operation Guide
Figure 23
Figure 25
6506-109-005 REV F
Figure 24
Figure 26
