LOADING THE COT INTO A VEHICLE WITH TWO OPERATORS - MANUAL METHOD (CONTINUED)
6. Operator 2 − Verify that the safety bar engages the safety
hook.
7. Operator 1 − Grasp the cot frame at the foot end. Lift the
foot end of the cot until the weight is off of the cot base.
Squeeze and hold the release handle as shown in Figure 39.
8. Operator 2 − Stabilize the cot by placing your hand on the
outer rail. Grasp the base frame as shown in Figure 40. After
the foot end operator has lifted the cot and squeezed the
release handle, raise the undercarriage until it stops in the
highest position and hold it there.
9. Both Operators − Push the cot into the patient compartment,
engaging the cot fastener (not included) as shown in Figure
41.
Note: When operating the manual back-up release handle, avoid
rapid lifting or lowering of the base or movement may appear
sluggish; lift with a slow constant motion.
www.stryker.com
Operation Guide
6506-109-005 REV F
Figure 39
Figure 40
Figure 41
