USING THE DEFIBRILLATOR PLATFORM

To install the defibrillator platform:
1. Place the defibrillator platform in the stored position as shown in Figure 79.
2. Open and expand the defibrillator platform legs as shown in Figure 80.
Figure 79
3. If the cot is equipped with an I.V. pole, raise the I.V. pole
(A) to the up position as shown in Figure 81.
4. Place the defibrillator platform on the cot frame as
shown in Figure 81. Position the inside legs (B) of the
defibrillator platform toward the head end of the cot to
properly fit the defibrillator platform on the cot frame.
www.stryker.com
Operation Guide
A
6506-109-005 REV F
Figure 80
B
Figure 81
