USING THE DEFIBRILLATOR PLATFORM (CONTINUED)
English
5. Place the latch hook (C) under the cot litter frame or foot end
fastener and push the tab (D) up until it locks into place with
an audible click as shown in Figure 82. Repeat on the other
side of the defibrillator platform.
Notes:
• For Power-LOAD compatible cots, you must lengthen and
attach the straps to the foot end fastener as indicated
in Figure 83.
• If the defibrillator platform is not securely attached to the
cot when both latch hooks are engaged or if you cannot
secure the latch hooks around the cot litter frame,
unlatch the tab (E), loosen or tighten the strap (F) until
the proper adjustment is achieved, and then push the
tab (E) up until it locks into place with an audible click
(Figure 84).
WARNING
To avoid the risk of patient injury or equipment damage, ensure
that you properly mount and secure the defibrillator platform to
the cot.
6. Ensure that the defibrillator platform is properly secured to
the cot.
7. Place the defibrillator on the defibrillator platform and secure
the straps.
WARNING
• To avoid the risk of patient injury or equipment damage, you
must use the provided straps to secure the defibrillator to the
defibrillator platform.
• Due to the difference in sizes and shapes of available
defibrillators, you may have to change the location and
adjustment of the straps that secure the defibrillator to the
defibrillator platform. To avoid the risk of patient injury or
equipment damage, use and adjust all straps properly to
ensure the security of the defibrillator.
• To avoid the risk of patient injury or equipment damage, the
weight placed on the defibrillator platform must not exceed 30
lb (13.6 kg).
Return To Table of Contents
1-68
Operation Guide
E
6506-109-005 REV F
D
C
Figure 82
Figure 83
Figure 84
