ZONE
ZONE 1 _ _ _ _ _ _ _ _ M
1
ZONE 2 _ _ _ _ _ _ _ _ M
2
ALL ZONES _ _ __ _ _ M
3
GROUP
NO GROUP_ _ _ _ _ _ _ _ M
1
NO GROUP_ _ _ _ _ _ _ _ M
2
NO GROUP_ _ _ _ _ _ _ _ M
3
To display the subsequent or previous inputs, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
GPI NAME
1 KEY 1 CONSOLLE 1 _
2 KEY 2 CONSOLLE 1 _
3 KEY 3 CONSOLLE 1 _
GPI NAME
4 KEY 4 CONSOLLE 1 _
5 MESSAGE 1_ _ _ _ _ _
6 MESSAGE 2_ _ _ _ _ _
To exit from the submenu, press ESC and proceed as described in the section EXIT FROM A MENU.
DEFINING THE RELAYS ASSOCIATED TO THE EVENT
This submenu is used for defining the relays to be switched when the GPI input is driven, indicated in the field RLY.
A maximum of 4 relays with normally open contact and a maximum of 4 relays with normally closed contact can be switched. To access
the submenu, move the selection point to any of the fields of the GPI input to be configured, and press F1. The fields described below ap-
pear on the control unit display.
N. Indicates the progressive number of the relay with normally open contact or with normally closed contact associated with the
event (max. 4 per type).
RELAY N.O. Used for selecting a relay with normally open contact (N.O.) to be switched to closed. Use the + and - keys to select the na-
me of the relay from those previously defined using the RELAY CONFIGURATION menu. If you choose the NO RELAY option
(default selection), no relay is selected.
RELAY N.C. Used for selecting a relay with normally closed contact (N.C.) to be switched to open. Use the + and - keys to select the na-
me of the relay from those previously defined using the RELAY CONFIGURATION menu. If you choose the NO RELAY option
(default selection), no relay is selected.
The first screen only shows the first 6 relays: 3 with normally open contact and 3 with normally closed contact. To display the subsequent or
previous relays, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
N. RELAY N.O.
RELAY 1 _ _ _ _ _ _ _ M
1
RELAY 3 _ _ _ _ _ _ _ M
2
NO RELE' _ _ _ _ _ _ M
3
N. RELAY N.O.
RLY 3 _ _ _ _ _ _ _ M
2
NO RELAY _ _ _ _ _ _ M
3
NO RELAY _ _ _ _ _ _ M
4
To exit from the submenu, press ESC and proceed as described in the section EXIT FROM A MENU.
GROUP
NO GROUP _ _ _ _ _ _ _
NO GROUP _ _ _ _ _ _ _
NO GROUP _ _ _ _ _ _ _
→
ACTION RLY(F1)
CONSGPI1 _ _M
CONSGPI1 _ _M
CONSGPI1 _ _M
Pag ↓
ACTION RLY(F1)
CONSGPI1M
PLAYBACKM
PLAYBACKM
RELE' N.C.
RLY 2 _ _ _ _ _ _ _ M
NO RELAY_ _ _ _ _ _ M
NO RELAY_ _ _ _ _ _ M
Pag ↓
RELAY N.C.
NO RELAY_ _ _ _ _ _ M
NO RELAY _ _ _ _ _ _ M
NO RELAY _ _ _ _ _ _ M
