STATUS Indicates the operating status of the A.C.U., which is continuously updated according to the various events that occur. The
following may be displayed:
• N.C. -
• FAULT -
• NOT INS. -
• WORKING - Indicates that the A.C.U. is inserted and is operating correctly.
INSERT Used for activating or disactivating a NORMAL or BACKUP A.C.U. configured with either manual or automatic activa-
tion/disactivation mode (MODE field of the ACU configuration menu).
Either a NORMAL or a BACKUP unit can be activated or disactivated manually at any moment, for example, when you need
to carry out a test to check the automatic activation of the respective backup.
Use the + and - keys to select one of the following options:
• ON – A.C.U. activated..
• OFF – A.C.U. disactivated.
IMPORTANT NOTES
• When it is not possible to modify the parameter of the INSERT field, an acoustic warning signal is generated ("beep").
• The NORMAL units are normally activated (ON); the BACKUP units are always normally disactivated (OFF).
• When a NORMAL unit is disactivated and the group of A.C.U.s to which it belongs includes a backup amplifier that is not
controlled by an RB 3300 back-amplifier board, this amplifier is always automatically activated in place of the primary
amplifier.
To display the subsequent or previous A.C.U.s, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
ACU TYPE
1 NORMAL
2 BACKUP
3 BACKUP
ACU TYPE
4 BACKUP
5 NORMAL
6 BACKUP
Press ESC to exit from the submenu; the new settings are stored automatically.
The following examples can help to clarify the operation of the A.C.U.s with different configurations
Example 1: manual exchange from a NORMAL unit to a BACKUP unit
A.C.U. configuration:
a) A.C.U. 1 of NORMAL type configured as MANUAL.
b) A.C.U. 2 of BACKUP type configured as MANUAL.
The following screen appears on the display of the CP 3100 control unit:
ACU TYPE
1 NORMAL
2 BACKUP
Operations to be carried out:
1) In the INSERT field of A.C.U. 1, select the OFF option; the item NOT INS. consequently appears in the respective STATUS field.
2) To insert the backup, a MANUAL OPERATION must be carried out on A.C.U. 2: in the INSERT field of this unit, select the ON option; the
item WORKING appears in the related STATUS field.
The following screen then appears on the CP 3100 control unit display:
ACU TYPE
1 NORMAL
2 BACKUP
Indicates a communication problem between the CP 3100 control unit and the A.C.U. (see the section DE-
TAIL OF ALARMS ON THE A.C.U.s). This indication can take place at any moment, and represents an alarm
status.
Indicates the activation of an alarm of the PA FAULT or OVL type on the A.C.U. (see the section DETAIL OF
ALARMS ON THE A.C.U.).
Indicates that the A.C.U. is not inserted but is operating correctly and is in communication with the CP 3100
control unit.
GROUP STATUS
01 N.C.
01 N.C.
01 N.C.
Pag ↓
GROUP STATUS
01 N.C.
02 N.C.
02 N.C.
GROUP STATUS
01 WORKING
01 NOT INS.
GROUP STATUS
01 NOT INS.
01 WORKING
INSERT
OFFM
OFFM
OFFM
INSERT
OFFM
OFFM
OFFM
INSERT
ONM
OFFM
INSERT
OFFM
ONM
