DISPLAY OF ALARM EVENTS

This procedure makes it possible to display the alarm events that have occurred since the system was switched on, and can be used when
the PRINT MODE: NO option has been selected in the PRINTER OPTIONS submenu of the SYSTEM configuration menu (see the section
USING THE "SYSTEM" MENU). After displaying the submenus of the ALARMS menu, press F1 to display the alarm events.
VISUALIZZAZIONE CAMPI ALLARME
AUDIO INPUT PROCESSORS
AUDIO OUTPUT PROCESSORS
PIGIARE F1 PER VEDERE ALLARMI
For each alarm event, a screen is shown on the control unit display containing the following information.
• Number of the alarm event and total number of alarms.
• Date on which the alarm event occurred.
• Time at which the alarm event occurred.
• Device that activated the alarm. The abbreviations that may appear are:
– INPUT PROC. – Indicates an IB 3210 / IB 3280 AUDIO INPUT board.
– OUTPUT PROC. - Indicates an OB 3230 AUDIO OUTPUT board.
– GPI ALARMS - Indicates an IO 3250 digital INPUT/OUTPUT board.
– CONSOLE - Indicates a BM 3616 digital console.
– ACU - Indicates an RB 3300 back-amplifier board.
The related identification number is indicated next to the name of the device.
• Type of event that caused the alarm. The types that may be shown depend on the specific device.
The example below shows 5 alarm events. To view the subsequent or previous events, use the + (forward) and - (back) keys.
SYSTEM ALARMS OVERVIEW
AUDIO INPUT PROCESSORS
AUDIO OUTPUT PROCESSORS
PRESS F1 TO VIEW CURRENT ALARMS
