AUDIO SETTINGS ("AUDIO PROCESS" menu)

RCF RX 3000 AUDIO SYSTEM
F1 : CONFIGURATION
F2 : ALARMS
" # # # # # # # # # # # # # #
Using the AUDIO PROCESS menu, you can quickly set a number of audio parameters, manually activate and disactivate the A.C.U.s, and
monitor the audio signals handled by the system. To access this menu, from the main menu of the control unit, press F4. The following sub-
menus appear on the control unit display:
• ADJUST AUDIO INPUT
• ADJUST AUDIO OUTPUT Menu for adjusting the level of the audio signals on the outputs of the OB 3230 AUDIO OUTPUT boards.
• INSERT BACKUP ACU
• MONITOR OPERATIONS
The settings made using the AUDIO PROCESS menu are applied immediately, without the need to use the STORE CONFIG. option of the
main menu (i.e. no need to store a new configuration). The first screen only shows the first 3 submenus; to display the subsequent subme-
nus, use the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
AUDIO ADJUST OPTIONS
ADJUST AUDIO INPUT
ADJUST AUDIO OUTPUT
INSERT BACKUP ACU
AUDIO ADJUST OPTIONS
ADJUST AUDIO OUTPUT
INSERT BACKUP ACU
MONITOR OPERATIONS

USING THE "ADJUST AUDIO INPUT" MENU

AUDIO ADJUST OPTIONS
ADJUST AUDIO INPUT
ADJUST AUDIO OUTPUT
INSERT BACKUP ACU
From the menu AUDIO PROCESS of the control unit, use the keys ↑ / ↓ and/or pag ↑ / pag ↓ to move the selection point to the ADJUST
AUDIO INPUT submenu and press ENTER. The fields described below appear on the control unit display.
INPUT NAME Indicates the name of the input to be adjusted. The names displayed are those associated to the various inputs by means
of the INPUT PROCESSORS configuration menu.
GAIN dB Used for adjusting the gain of the input. Use the + and - keys to set the gain level between the values 0 dB and +20 dB.
The adjustment is made in 1 dB intervals.
IMPORTANT NOTES
• In order to avoid problems due to saturation of the input, evaluate the gain adjustment carefully if it is made at the same
time as the tone control adjustment.
BASS/TREBLE Used for activating or disactivating the two tone controls of the input (trimmers) for adjusting the high and low frequencies.
Use the + and - keys to select one of the following options:
• ON - Tone controls activated.
• OFF - Tone controls disactivated.
To display the subsequent or previous inputs, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
INPUT NAME
SOURCE 1
SOURCE 2
SOURCE 3
F3: STORE CONFIG.
F4: AUDIO PROCESS
03 NOV 1999
Menu for adjusting the gain of the inputs of the IB 3210 / IB 3280 AUDIO INPUT boards. This menu also makes
it possible to activate or disactivate the tone controls of the inputs (treble/bass).
Menu for manual activation/disactivation of the A.C.U.s (see the section AMPLIFIER CONTROL UNITS), and
for viewing the operating status of these units.
Menu for listening through the monitor speaker of the control unit to the audio signals handled by the system
(e.g. input signals, output signals, signals on the speaker outputs of the amplifiers controlled by the A.C.U.s).
This menu can also be used for controlling the levels of the audio signals being monitored.
Pag ↓
GAIN DB
00
00
00
Pag ↓
ENGLISH _ _ _ M
15:29:52
BASS/TREBLE
OFFM
OFFM
OFFM
