INPUT BOARD REV
INP. PROC. 1 1.0
INP. PROC. 2 1.0
INP. PROC. 3 1.0
INPUT BOARD REV
INP. PROC. 4 1.0
INP. PROC. 5 1.0
INP. PROC. 6 1.0
To exit from the submenu, press ESC.

DETAIL OF ALARMS ON THE OB 3230 AUDIO OUTPUT BOARDS

SYSTEMS ALARMS OVERVIEW
AUDIO INPUT PROCESSORS
AUDIO OUTPUT PROCESSORS
PRESS F1 TO VIEW CURRENT ALARMS
For a detailed report on the current status of alarms related to the OB 3230 AUDIO OUTPUT boards, from the ALARMS menu of the control
unit, use the ↑ / ↓ and/or pag ↑ / pag ↓ keys to move the selection point to the AUDIO OUTPUT PROCESSORS submenu and press EN-
TER. The fields described below appear on the control unit display.
OUTPUT BOARD Indicates the identification number of the OB 3230 AUDIO OUTPUT board (see the section CHARACTERISTIC PARAME-
TERS).
REV Indicates the software version of the AUDIO OUTPUT board.
DCI Indicates an alarm caused by a communication problem between the board and the control unit. When the alarm is active,
the symbol X is shown in the field.
EEP Indicates an alarm caused by a failure or defective operation of the board's EEPROM memory. When the alarm is active, the
symbol X is shown in the field.
RST Indicates an alarm caused by the reset of the board microprocessor for reinitializing its operation ("watchdog" function).
When the alarm is active, the symbol X is shown in the field.
CFG Indicates an alarm caused by incomplete configuration of the board on the part of the control unit (e.g. the configuration
was interrupted by board removal). When the alarm is active, the symbol X is shown in the field.
POW Indicates an alarm caused by a power supply voltage to the board that is too low or absent. When the alarm is active, the
symbol X is shown in the field.
AUD Indicates an alarm caused by a failure on one or more audio outputs of the board. When the alarm is active, the symbol X
is shown in the field.
KO Indicates an alarm caused by the removal of the board (e.g. to repair it). In this condition, the board no longer communica-
tes with the CP 3100 control unit, and the control of all the other alarms causes is suspended. To use the previously remo-
ved board again, the system must be reconfigured as described in the section STORING A CONFIGURATION. When the
alarm is active, the symbol X is shown in the field.
The first screen only shows the first 7 fields (REV, DCI, EEP, RST, CFG, POW, AUD) of the first 3 OB 3230 boards. To display the next field,
press →; to display the previous field, press ←.
OUTPUT BOARD REV
OUT. PROC. 1 1.0
OUT. PROC. 2 1.0
OUT. PROC. 3 1.0
REV DCI EEP
1.0
1.0
1.0
To display the next or previous OB 3230 AUDIO OUTPUT boards, press the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
DCI EEP RST
Pag ↓
DCI EEP RST
DCI EEP RST CFG
→
RST CFG POW AUD
CFG KO
CFG KO
ALARMS
[ ]
[ ]
POW AUD
KO
