ALARM STATUS DISPLAY ("ALARMS" menu)

RCF RX 3000 AUDIO SYSTEM
F1 : CONFIGURATION
F2 : ALARMS
" # # # # # # # # # # # # # #
To access the menus used for displaying the current status of the alarms handled by the system (see the section SYSTEM ALARMS), from
the main menu press F2. The following submenus appear on the control unit display.
• AUDIO INPUT PROCESSORS
• AUDIO OUTPUT PROCESSORS
• GPI PROCESSORS
• DIG.CONSOLLES
• (ACU) AMPLIFIERS
• GPI ALARMS
• EMERGENCY
• FIREMAN
• SYSTEM ALARMS
Next to each submenu, the ALARMS field indicates the status of the alarm of the device/event to which the submenu refers, which is conti-
nuously updated. Specifically, the indications are the following:
• [ X ], when one or more alarms are activated.
IMPORTANT NOTE
• The submenus of the ALARMS menu also show "status" or "data" (e.g. REV, ALC fields) which do not indicate an alarm condition.
The first screen only shows the first 2 submenus; to display the next submenus, use the ↑ / ↓ and/or pag ↑ / pag ↓ keys.
SYSTEM ALARMS OVERVIEW
AUDIO INPUT PROCESSORS
AUDIO OUTPUT PROCESSORS
PRESS F1 TO VIEW CURRENT ALARMS
SYSTEM ALARMS OVERVIEW
GPI PROCESSORS
DIG. CONSOLLES
PRESS F1 TO VIEW CURRENT ALARMS
SYSTEM ALARMS OVERVIEW
(ACU) AMPLIFIERS
GPI ALARMS
PRESS F1 TO VIEW CURRENT ALARMS
SYSTEM ALARMS OVERVIEW
EMERGENCY
FIREMAN
PRESS F1 TO VIEW CURRENT ALARMS
SYSTEM ALARMS OVERVIEW
FIREMAN
SYSTEM ALARMS
PRESS F1 TO VIEW CURRENT ALARMS
ENGLISH _ _ _ M
F3: STORE CONFIG.
F4: AUDIO PROCESS
03 NOV 1999
Gives a detailed indication of alarms related to the operation of the IB 3210 / IB 3280 AUDIO INPUT
boards.
Gives a detailed indication of alarms related to the operation of the OB 3230 AUDIO OUTPUT boards.
Gives a detailed indication of alarms related to the operation of the IO 3250 digital INPUT/OUTPUT
boards.
Gives a detailed indication of alarms related to the operation of the BM 3616 digital consoles.
Gives a detailed indication of alarms related to the operation of the A.C.U.s (RB 3300 back-amplifier
boards).
Gives a detailed indication of the status of warnings controlled by the inputs of the IO 3250 digital IN-
PUT/OUTPUT boards.
Gives a detailed indication of the status of alarms controlled by the ALARM key of the BM 3616 digi-
tal consoles.
Gives a detailed indication of the status of alarms controlled by the inputs of the IO 3250 digital IN-
PUT/OUTPUT boards configured as FIREMAN.
Gives a detailed indication of the status of alarms related to the operation of the components of the
CP 3100 control unit.
ALARMS
Pag ↓
ALARMS
Pag ↓
ALARMS
Pag ↓
ALARMS
Pag ↓
ALARMS
15:29:52
• [ ], when no alarm has been activated.
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
