Installation and operating instructions Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D
Description of the pump
Property
Protection class
Ambient temperature dur-
ing operation min./max.
Temperature during stor-
age min./max.
Temperature during trans-
port min./max.
Relative humidity
Installation height max.
Insulation class
Pollution degree
Motor protection
Overvoltage protection
Overvoltage category
Protection function control
terminals
Electromagnetic compat-
ibility
Interference emission in
acc. with:
Interference immunity in
acc. with:
4)
Sound-pressure level
Nominal diameters DN
Pipe connections
Max. permissible operating
pressure
Permissible min./max. fluid
temperature
5)
Permissible fluids
Table 5: Technical data
1)
TN and TT power supplies with earthed live wires are not permitted.
2)
For more detailed, product-specific information such as power consumption, dimen-
sions and weights, refer to the technical documentation in the catalogue or Wilo-Select
online.
3)
Over Voltage Category III + Surge Protective Device/Metall Oxid Varistor
4)
Average value of the sound-pressure levels on a spatially rectangular measuring sur-
face at a distance of 1 m from the pump surface in accordance with DIN EN ISO 3744.
5)
For more information about permissible fluids, see the "Fluids" section.
Value
IP55
0 °C ... +50 °C
-30 °C ... +70 °C
-30 °C ... +70 °C
< 95 %, non-condensing
2000 m above sea level
F
2
integrated
integrated
3)
OVC III + SPD/MOV
SELV, galvanically isolated
EN 61800-3:2018
EN 61800-3:2018
L < 68 dB (A) ⃒ ref.
pA,1 m
20 µPa
Stratos GIGA2.0-I/
Stratos GIGA2.0-D:
40/50/65/80/100/125
Flanges PN 16
16 bar (up to +120 °C)
13 bar (up to +140 °C)
-20 °C ... +140 °C
Heating water in accordance
with VDI 2035 Part 1 and
Part 2
Cooling/cold water
Water-glycol mixture up to
40 % Vol.
Water-glycol mixture up to
50 % Vol.
Heat carrier oil
Other fluids
en
Note
EN 60529
Lower or higher ambient
temperatures on request
> +60 °C limited to a dur-
ation of 8 weeks.
> +60 °C limited to a dur-
ation of 8 weeks.
DIN EN 61800-5-1
Overvoltage Cat-
egory III + Surge Protect-
ive Device/ Metal Oxide
Varistor
Residential environment
6)
(C1)
Industrial environment
(C2)
Depending on pump type
EN 1092-2
Depending on the fluid
Standard version
Standard version
Standard version
Only for special version
Only for special version
Only for special version
