Installation and operating instructions Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D
Diagnostics and measured values
Configuring the sensor source in the return
In the "Diagnostics and measured values" menu
1. "Heating/cooling quantity measurement"
2. "Sensor return temperature"
3. Select "Select sensor source".
Potential sensor source options
ƒ
Analogue input AI1 (assigned with differential pressure sensor)
ƒ
Analogue input AI2 (only active sensor)
ƒ
Analogue input AI3 (PT1000 or active sensor)
ƒ
Analogue input AI4 (PT1000 or active sensor)
ƒ
CIF module
Configuring the sensor position in the feed
1. "Heating/cooling quantity measurement"
2. "Sensor feed temperature"
3. Select "Select sensor position".
Select "Feed" or "Return" as the sensor positions.
Configuring the sensor position in the return
1. "Heating/cooling quantity measurement"
2. "Sensor return temperature"
3. Select "Select sensor position".
Select "Feed" or "Return" as the sensor positions.
Potential sensor position options
ƒ
Analogue input AI2 (only active sensor)
ƒ
Analogue input AI3 (PT1000 or active sensor)
ƒ
Analogue input AI4 (PT1000 or active sensor)
ƒ
BMS (Building management systems)
ƒ
Feed
ƒ
Return
ƒ
Primary circuit 1
ƒ
Primary circuit 2
ƒ
Secondary circuit 1
ƒ
Secondary circuit 2
ƒ
Hall
NOTICE
When the heating or cooling quantity measurement is activated, this menu can be
used to read the total overall heating or cooling quantity. The current heating and
cooling capacity is displayed. If desired, the heating quantity can be re-set to 0 here.
, select
