18.3

Error messages

Installation and operating instructions Wilo-Stratos GIGA2.0-I, Wilo-Stratos GIGA2.0-D
Faults, causes and remedies
Diagnostics help Description
Overview of hydraulic Overview of current hydraulic
data operating data.
Overview of electrical Overview of current electrical
data operating data.
Overview of analogue Overview of settings
input (AI1)
e.g. type of use
differential pressure sensor,
signal type 2 ... 10 V
Overview of analogue e.g. type of use
input (AI2) differential pressure sensor,
signal type 4 ... 20 V for con-
trol mode index circuit evalu-
ator Δp-c
Overview of analogue e.g. type of use
input (AI3) temperature sensor,
signal type PT1000 for con-
trol mode ΔT-c
Overview of analogue e.g. type of use
input (AI4) temperature sensor,
signal type PT1000 for con-
trol mode ΔT-c
SSM relay forced control Forced control of the SSM re-
lay
in order to check the relay
and electrical connection.
SBM relay forced control Forced control of the SBM re-
lay,
in order to check the relay
and electrical connection.
Device information Display of different device in-
formation.
Manufacturer contact Display of contact data of the
factory customer service.
Table 54: Selection options – Diagnostics help
1)
For information about type of use, signal type and functions, see "Application and
function of the analogue inputs AI1 ... AI 4" [} 219] section.
2)
See "SSM/SBM relay forced control" [} 215] section.
Displays an error message on the display
ƒ
The status display will be in red colour.
ƒ
Error message, error code (E...), cause and remedy are described as text.
The pump is not operational if an error has occurred. If the pump identifies as part of
permanent monitoring that the cause of the error no longer applies, the error mes-
sage is revoked and operation resumes.
en
Display
• Actual delivery head
• Actual volume flow
• Actual speed
• Actual fluid temperature
• Active restriction
Example: max. pump char-
acteristic curve
• Mains voltage
• Power consumption
• Consumed energy
• Active restriction
Example: max. pump char-
acteristic curve
• Operational hours
• Type of use
• Signal type
• Function
1)
• Type of use
• Signal type
• Function
1)
• Type of use
• Signal type
• Function
1)
• Type of use
• Signal type
• Function
1)
• Normal
• Forced active
• Forced inactive
2)
• Normal
• Forced active
• Forced inactive
2)
• Pump type
• Article number
• Serial number
• Software version
• Hardware version
• Contact data
