en
10.3.6 Sub-menu
10.3.7 "Settings" sub-menu
182
Commissioning
NOTICE
Setpoint adjustment is not possible when Dynamic Adapt plus is active.
NOTICE
Pressing the context button
further settings.
Pos. Name
1 Main menu over-
view
1.1 Status area:
error, warning or
process informa-
tion display
2 Title bar
3 Setpoint display
field
4 Setpoint editor
5 Active influences
6 Reset reference
7 Operating data and
measurement area
8 Context menu ref-
erence
Table 17: Home screen
Each sub-menu is made up of a list of sub-menu items.
Each sub-menu item consists of a title and an information bar.
The title lists an additional sub-menu or a downstream settings dialogue.
The information bar shows descriptive information about the available sub-menu or the
downstream settings dialogue. The information bar of a settings dialogue shows the set
value (e.g. a setpoint). With this display, you can check settings without having to open
the settings dialogue.
Different settings can be changed in the "Settings" menu
Turn the operating button to the "Gear wheel" icon
Press the operating button to change the focus to the "Settings" sub-menu.
Turn the operating button to the left or right to select a sub-menu item. The selected
sub-menu item has been highlighted in green.
Press the operating button to confirm your selection. The selected sub-menu or down-
stream settings dialogue appears.
will display additional context-related options for
Explanation
Selection of different main menus
Indicates an on-going process, warning or error message.
Blue: process or communication status display (CIF mod-
ule communication)
Yellow: Warning
Red: Fault
Grey: there are no processes running in the background,
there are no warning or error messages.
Display of currently set application and control mode.
Displays currently configured setpoints.
Yellow frame: you have pressed the operating button to
open the setpoint editor and change the value.
Display of influences on set control mode,
e.g. EXT. OFF. You can display up to five active influ-
ences.
Shows the value before having changed it when the set-
point editor is active.
The arrow shows that you can go back to the previous
value with the "Back" button.
Shows current operating data and measured values.
Offers context-related options in a separate context
menu.
to select the "Settings" menu.
.
