Bosch Rexroth TS 2plus Manuel D'utilisation page 75

3 842 531 138 (2013-06)
Längstransport · Longitudinal conveyor · Transport longitudinal
BS 2/C-100
b
Bandstrecke BS 2/C-100
BS 2/C-100 belt section
100 kg Section à bande BS 2/C-100
b 1) l 2)
[mm] [mm]
160 300-6000
240 300-6000
320 300-6000
400 300-6000
480 300-6000
640
300-6000
800
300-6000
1040
300-6000
160-1040
300-6000
Bandstrecke BS 2/C-250
BS 2/C-250 belt section
Section à bande BS 2/C-250
250 kg
b l
1) 2)
[mm] [mm]
160 300-6000
240 300-6000
320 300-6000
400 300-6000
480 300-6000
640 300-6000
800 300-6000
1040 300-6000
160-1040 300-6000
1) b = Spurbreite in Transportrichtung
2) l = Länge
3) v = Nenngeschwindigkeit;
N
v = 0: ohne Motor und ohne Getriebe
N
Sonderausführungen auf Anfrage
TS 2plus 4.2
l
v 3) U, f
N
[m/min]  11-122
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
v U, f
3)
N
[m/min]  11-122
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
1) b = Track width in direction of transport
2) l = Length
3) v = Nominal transportation speed;
N
v = 0: without motor or gear
N
Special models on request
Bosch Rexroth AG
MA = Motoranordnung
MA = Motor layout
MA = Disposition du moteur
R
M
00013196.eps
AT MA KA
S; K R; L N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; M N; A
S; K R; L; (M) N; A
AT MA KA
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
S; K R; L N; A
1) b = Ecart. de voie en direction du transport
2) l = Longueur
3) v = Vitesse nominale de transport ;
N
v = 0 : sans moteur et sans engrenage
N
Versions spéciales sur demande
3–29
1
2
3
4
5
00116761.eps
MA = L
6
7
Nr./No./N°
8
3 842 999 917
b = ... mm
9
l = ... mm
v = ... m/min
N
U = ... V
10
f = ... Hz
AT = ...
MA = ...
11
KA = ...
12
Nr./No./N°
13
3 842 999 985
b = ... mm
14
l = ... mm
v = ... m/min
N
U = ... V
f = ... Hz
15
AT = ...
MA = ...
KA = ...
16
17
