Bosch Rexroth TS 2plus Manuel D'utilisation page 187

3 842 531 138 (2013-06)
Quertransport · Transverse conveyor · Transport transversal
EQ 2/T
00012788.eps
Elektrischer Quertransport EQ 2/T
EQ 2/T electrical transverse conveyor
Convoyeur transversal électrique EQ 2/T
60 kg
b b
Q L
[mm] [mm]
160 160
1) 320-6000
160 240
320-6000
160 320 320-6000
240 160 320-6000
1)
240 240 320-6000
240 320 320-6000
240 400 320-6000
320 160 320-6000
1)
320 240 320-6000
320 320 320-6000
320 400 320-6000
400 240 320-6000
400 320 320-6000
400 400 320-6000
400 480 320-6000
480 320 320-6000
480 400 320-6000
480 480 320-6000
640 400 320-6000
640 480 320-6000
800 400 320-6000
800 480
320-6000
1) Nicht geeignet für Strecken
ST 2/B-100, ST 2/C-100 und ST 2/R-100.
TS 2plus 4.2
l
b
L
l v
N
[mm] [m/min]
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
0; 6; 9; 12; 15; 18
1) Not suitable for conveyor sections
ST 2/B-100, ST 2/C-100, and ST 2/R-100.
MA = R
U, f MA
 11-122
R; L
R; L
R; L
R; L
R; L
R; L
R; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
R; M; L
1)
ST 2/B-100, ST 2/C-100 et ST 2/R-100.
Bosch Rexroth AG
b
Q
AT ZA Nr./No./N°
3 842 999 895
S; K N; A
S; K N; A b = ... mm
Q
S; K N; A b = ... mm
L
S; K N; A l = ... mm
S; K N; A v = ... m/min
N
S; K N; A U = ... V
S; K N; A f = ... Hz
S; K N; A MA = ...
S; K N; A AT = ...
S; K N; A ZA = ...
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
S; K N; A
N'est pas adapté pour les sections
5–11
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
