92 AVENTICS | INTERBUS S | R412005743–BDL–001–AD
Commissioning and Operation
7.3

Commissioning the bus coupler

Before commissioning the system, the following steps must
have been carried out and completed:
You have assembled the valve system and the bus coupler
W
(see "Assembling the valve system with the bus coupler" on
page 70).
You have connected the bus coupler (see "Connecting the
W
bus coupler electrically" on page 71).
You have made the presettings and configured the system
W
(see "Making presettings" on page 80).
You have configured the bus master so that it controls the
W
valves and the input module correctly.
You have carried out the diagnostic test on the input/output
W
modules (see "Testing and diagnosis on the bus coupler" on
page 89).
Commissioning and operation may only be carried out by
qualified electrical or pneumatics personnel or an instructed
person under the direction and supervision of qualified
personnel (see "Personnel qualifications" on page 61).
Uncontrolled actuator movements when the pneumatics are
switched on
Danger of injury if the system is in an undefined state or the
manual overrides are set to position "1".
Put the system in a defined state before switching it on.
O
Set all manual overrides to position "0".
O
Make sure that no personnel are within the hazardous
O
zone when the pressure is switched on.
Also observe the applicable instructions and safety
O
information in the VS operating instructions.
1. Switch on the operating voltage.
2. Check the LED displays on all modules.
3. Switch on the compressed air supply.
CAUTION
