Total Overview Of The Valve System - Aventics INTERBUS S Mode D'emploi

2
1
7
Fig. 1: Overview: bus coupler sample configuration with I/O modules and mounted VS
1 E end plate
1)
2 Output module
1)
3 Input module
4 Bus coupler, type B-design
1)
A maximum of 6 modules total (input and/or output modules) can be connected in any combination
(e.g. 3 input and 3 output modules).
2)
With its own operating instructions.
AVENTICS | INTERBUS S | R412005743–BDL–001–AD
5.1

Total overview of the valve system

The valve system consists of the following parts as illustrated in
Fig. 1 (depending on the order):
5
4
3
6
5 EP end plate
2)
6 Valve system
7 FE connection on the end plate
65
Device description
