54 AVENTICS | AS-i | R499050017–BDL–001–AE
Device description
3
Fig. 1: Overview: Sample configuration with AS-i 8DI/8DO-AUX or AS-i 8DO-AUX and assembled VS
1 8DO-AUX bus coupler
1
2 Valve terminal
5.1

Overview of the valve system and modules

The valve system consists of the following parts as illustrated in
Fig. 1 (depending on the order):
2
1
2
4
1) With its own operating instructions.
3 E end plate
4 8DI/8DO-AUX bus coupler
