AUX- and PWR-LED
Table 11: Diagnostic display on 8DI/8DO-AUX bus coupler
LED
POWER Fault1
Off Off
Green Off
Green Red
Green Red
Green Off
Green Flashes
red
Green Flashes
red
Table 12: Diagnostic display on 4DI/4DO-AUX and 4DI/4DO bus coupler
LED
POWER Fault1
Off Off
Green Off
Green Red
Green Flashes
red
AVENTICS | AS-i | R499050017–BDL–001–AE
7.2

Test and diagnosis on the bus couplers

7.2.1

Reading the bus coupler diagnostic display

The LEDs on the front panel of the bus couplers show the status
messages of the following tables (Tab. 11, Tab. 12 and Tab. 13,
Tab. 14 on page 74) for the various module types.
Before commissioning and during operation, regularly
O
check bus coupler functions by reading the diagnostic
displays.
The AUX or PWR LED indicates whether there is load supply
voltage in the module (AUX/PWR LED illuminated green) or not
(AUX/PWR LED off).
Fault2 Description
Off No AS-i power supply available on bus
Off Cyclical I/O data traffic with both participants
Red No I/O data traffic
Off No I/O data traffic with participant 1
Red No I/O data traffic with participant 2
Off Short circuit/overload of sensor supply
W
Status bit S1 is set
W
Red Short circuit/overload of sensor supply
W
Status bit S1 is set
W
Also no I/O data traffic with participant 2
W
Description
No AS-i power supply available on bus
Cyclical I/O data traffic with both participants
No I/O data traffic
Short circuit/overload of sensor supply
W
Status bit S1 is set
W
Commissioning and operation
