Disposal
1)
8x input module
1)
8x input module
1)
8x output module
1)
8x output module
Accessories
Straight plug connector, with self-
clinching screw, M8x1, 3-pin
M8x1 protective cap for inputs (LE = 25 pieces)
M12x1 protective cap for inputs (LE = 25 pieces)
M12 Y-distributor with M12 self-clinching screw,
5-pin, 2x M12 cable socket, 1x M12 cable plug
1)
Delivery incl. 2 tie rods and 1 seal
Plug connector for power supply, M12x1 socket,
4-pin for cable Ø 4 – 8 mm, A-coded
Plug connector for input/output modules
11.1 8x input/output module, 8DI/8DO
11.2 Power plug for bus coupler and output
module
180° (X10, POWER)
90° (X10, POWER)
M12x1 plug, straight
M12x1 plug, angled
M12x1 dual plug for cable Ø
3 mm or 5 mm

12 Disposal

Dispose of the device in accordance with the currently
applicable regulations in your country.
Order code
8DI_M8
8DI_M12
8DO_M8
8DO_M12
Cable length 2 m
Cable length 5 m
Cable length
10 m
Order number
R412003489
R412000871
R412005968
R412000870
8946203602
8946203612
8946203622
R412003493
1823312001
8941002392
Order number
8941054324
8941054424
1834484222
1834484223
1834484246
