Array: The space between two objects on X direction
Array: The space between two objects on Y direction
Calculate by offset distance: The space of the graphs is calculated by offset distance.
(Figure 5-3(a))
Figure 5-3（a）Calculate by offset distance
Calculate by graph distance: The space of the graphs is calculated by graph distance.
(Figure 5-3(b))
If we select the array type is "Circle", we can see the figure 5-2(b):
: The graphs array is clockwise or anticlockwise.
Array number: The graph number.
Radius: The radius of the circle.
Start Angle: The angle between the starting graphs of the circle.
Angle: The angle between two graphs.

5.2 Transformation

When selected, a parameter setting box will appear as Figure 5-4 shows.
Figure 5-3（b）Calculate by graph distance
Figure 5-2-b Array dialog box(Circle)
72
