Angle：the slant angle of the rotary
Refresh：after updating the marking parameter, click it, let the software to read new parameters.
3 calibration ： similar with the inside calibration, during mark, use it to calibrate the marking
distortion.
Outside mark: in the F3 parameter, can choose X and Z in ID, during mark, software will
split the picture in X direction
1，rotary axis and z axis go to zero
2，find the focus
3，set ring mark parameters then refresh
4，calibration
5，mark
Inside mark:in the F3 parameter, can choose X and Z in ID, during mark, software will split
the picture in X direction
1，click inside ring mark
2，rotary axis and z axis go to zero, we suggest for z axis, use zero offset to find the focus.
Zero offset: current axis arrive at the zero point, then move some distance to find the focus.
3，set ring mark parameters and refresh
4，calibration
5，mark
105
