Object List; Object Properties - Vevor Flm-R30-Ft Mode D'emploi

2.10 Object List

Object List is in the left side of the main interface window.
Marked objects are grouped into an object structure or ungrouped to many objects. (Figure
2-12)
When in marking process, system will follow the order to mark the objects listed.
Users can rearrange the list by directly dragging the object up/down or right keyboard to
change the marking order.
Users can double click the object bar to name them.

2.11 Object Properties

Object Properties are displayed in the left side of the main interface window
X position: the X coordinate of the

point in the left button corner of the
object selected.
Y position: the Y coordinate of the

point in the left button corner of the
object selected
Z position: the Z coordinate of

selected object
X Size: width of the object selected

Y Size: height of the object selected

Lock the current width/height
:

proportion of the object selected. If
user changes the object's size, system
Figure 2-12 Object List
Figure 2-13 Object Property
15
