EN
-
Mass (recommended): click on the icon
address with the IP of your parent. To do so, fill in the SOURCE IP ADDRESS field with the IP
192.168.0.10, the DESTINATION IP ADDRESS field with the IP of your matrix and select the
screen where you want to apply this change with the RANGE dropdown where ALL PAGES
allows you to apply the change to all the screens at the same time and the rest of the available
options will be each of the existing screens in the uploaded file. Press OK to apply the change
or CANCEL to discard it.
3.- To add new elements click and drag the elements from the toolbar to the position on the page where
you want to place it, make the configuration of the element in the properties panel on the right. Repeat
this action until you have added all the necessary elements.
4.- Arrange the elements on the page using the editing tools in the top panel. For better handling, if several
elements go together, it is recommended to group them. To do this, select them and right-click on them
with the options GROUP or UPGROUP.
NOTE: the elements shall be placed in different layers with the last element added at the front and the
first at the back.. If you want to change the organisation of any of them, you must select it and click on
it with the right mouse button in order to organise it: SEND TO BACK, BRING FORWARD, SEND TO
BOTTOM or BRING TOP.
5.- Edit the background
6.- Create as many pages as you want using the top menu option
7.- Once finished save the file to your PC from the top menu FILE > SAVE AS... or by clicking on the icon
LOAD PAGES ON ONE SCREEN
1.- Open the APP on the TAB-10-16, tablet or iPad.
2.- In the PC software, go to the SETTINGS > USER INTERFACE menu and a new window will appear.
3.- Load the previously designed page file on the PC from the menu FILE > OPEN or by clicking on the
icon
.
4.- To load them into the device's APP, click on the
devices. Please note that for the devices to be detected the APP must be open on the tablet or iPad.
5.- Select 1 or more tablet/iPad by ticking/unticking on each of the lines, click on the SYNC button to
synchronise and wait a few seconds until the process is finished. A % bar will indicate the progress of
the charge and show
IMPORTANT: it is recommended to save all designed screens on your PC and synchronise only when
you are sure, as it is not possible to revert the changes nor download the file from the screen to the PC.
icon and the pop-up window will show the active
when it has been completed.
- 54 -
in the top menu and replace the default IP
Default IP
Matrix IP
Display on which
to make the
modification
.
.
