EN
BUILT-IN RECORDER
With the USB-A to USB-A cable connected between the matrix and the
computer with the control software, the computer will be able to access the
sound board of the matrix (USB OUTPUT).
Before using the recorder, configure its settings:
1.- Press the
button.
2.- In the next window click the
3.- And in the pop-up window configure the options shown:
-
SOUND CARD: microphone to be recorded from those available on the computer.
-
CHANNEL: channel on which the audio will be recorded: LEFT (left channel), STEREO (both channels)
or RIGHT (right channel).
-
SAVE PATH: path on the computer where to store the recording files.
4.- Go to the MATRIX tab and assign all the inputs you want to record with the recorder to the USB output.
Once this is set up, you will be able to record. Press the button
start recording and
saved on the PC under the name
"Recorder AAAA-MM-DD HH-MM-SS.wav".
Stored recordings can be accessed via the
of the recordings, 2 icons will appear: to delete the recording
access the folder containing the recording
there is a button
computer.
MAIN SECTIONS
It is possible to control several matrices from this software, with tabs at the
top of the software allowing you to access the settings of one or the other matrix quickly. Press the
to add more devices. To make it easier to identify the marices, go to the SETTING > DEVICE SETTING menu
and rename each of them.
To the left of the name of each of the matrices you will see a coloured identifier which will be grey when the
matrix is offline and green when it is online.
To connect or disconnect a matrix, use the DEVICE LIST button at the top right of the window. This option
displays a list of all active devices automatically detected on the network via UDP discovery, i.e. it will detect
all the matrices connected to the same physical network even if they do not belong to the same subnetwork
due to their network configuration. To add new matrices to this list you can either click the
manually enter the IP address of the matrix or click the
button.
to stop recording . The recordings are automatically
to delete all recordings from the list and from the
button. If you click on one
. At the bottom of this screen
button to refresh the list of matrices.
- 20 -
to
or to
button
button and
