OUTPUTS TAB
It shows only the output channels at the bottom and the DSP modules associated with the selected channel
at the top. For quick access to each of the DSP modules assigned to the selected channel, use the list to
the right of this upper block.
For more information on DSP modules go to DSP MODULES FOR INPUTS/OUTS.
Configuration of
DSP modules
of the channel
Selected channel
METERS TAB
Displays the input and output channels and the recorder player at the bottom. And, at the top, shortcuts to
the channels, the configuration of each channel and the main parameters of the METER system module.
This module graphically displays the level of inputs and outputs in real time.
Input channels level
Input channels level
OUTPUT Channels
falta acceso directo a canales
INPUT Channels
- 29 -
cambiar imnagen
OUTPUT Channels
Player/Recorder
EN
Direct access to the
other DSP modules
of the channel
