TAB-10-16, TABLETS ANDROID AND IPADS
This NMX system allows the connection of peripheral touch devices for remote control of the matrix.
FONESTAR offers the TAB-10-16 touchscreen with a 10" screen and Android operating system, although
it is also possible to use other tablets as long as their operating systems are Android 12 or higher or iPads
iOS 15 or higher. These screens show one or more screens with different controls that are created through
the PC software.
First of all you must connect the display to the network, the steps to follow are detailed in the CONNECTION
section. Once these steps have been carried out, you will find yourself on a screen similar to the one shown
below, if this is not the case, access the SETTINGS > USER SETTINGS menu in the PC software::
MENUS AND TOOLBARS
MENU
NEW PAGE: allows additional pages to be created and displayed in the software as a new tab.
SAVE: allows you to save the created page file on PC as a backup or to be loaded on the screens at a
later time. Also available is the "save as..." option in the top menu FILE > SAVE AS...
OPEN: allows you to open page files previously saved on PC. Also available in the top menu FILE > OPEN.
TEMPLATE: allows you to create different screen sizes as templates. Also available in the top menu
SETTINGS> TEMPLATES.
There are templates that you can make manually in the LOCAL TEMPLATE tab, or create automatically
in the DEVICE TEMPLATE tab. The latter will detect the connected screens to create appropriate page
dimensions.
SYNC: allows you to synchronise the page file that is loaded on the connected displays.
ROTATE: allows you to change the page orientation from vertical to horizontal and vice versa.
QUICKLY REPLACE IP ADDRESSES: allows you to massively replace one IP address with another in the
controls of one or all pages at a time.
: zoom for the display of the page on the screen.
- 50 -
