2.- In the MASTER matrix, go to SETTINGS > DEVICE SETTINGS. Enable the SET UP REDUNDANCY
option: ON and in the BACKUPDEVICEIP field that will appear below you will have to enter the IP
address of the SLAVE array. This matrix will display the
3.- At this point, presets and other settings made in the MASTER matrix will be automatically synchronised
in the SLAVE matrix.
PRESETS
A preset allows you to store all the parameters and settings for a particular scene. In this way, it is possible
to switch quickly from one configuration to another. Each matrix has 16 preset memories.
These preset files can be created from scratch or from a preset that already exists in the matrix. It is
recommended to store them on a PC as a backup and to be able to load them into other matrices at a later
date.
CUSTOMISE THE NAME OF A PRESET
To make it easier to identify each of the configured presets, it is recommended to rename them.
1.- With the matrix connected to the software, go to the SETTING > PRESET NAME... menu.
2.- In the new window, all the names for each preset will be displayed and you can edit the fields directly.
3.- Press the OK button to save the changes or CANCEL to discard them.
CREATE AN OFFLINE PRESET FILE
When the matrix is not connected, we can create files containing the configuration to load them into the
matrix later in one of its presets or save them as a backup.
1.- Open a new device tab by choosing the type of matrix, 8 or 16 channels, required.
2.- Make the desired settings.
3.- Once you have finished save the file to your PC from the menu FILE > SAVE AS....
4.- Add a name that allows you to distinguish the configuration from others that you make to store in other
presets.
CREATE A PRESET FILE ONLINE
When the matrix is connected we can create files containing the configuration of a preset to load them into
other matrices at a later time or save them as a backup of the configuration.
1.- Open a new device tab by choosing the type of matrix, 8 or 16 channels, required.
2.- Connect a matrix by clicking on DEVICE LIST in the upper left corner and then pressing the CONNECT
button of the desired matrix. The configuration of the preset selected in the drop-down menu will be
automatically loaded
3.- (Optional) Make the desired settings.
4.- Once you have finished save the file to your PC from the menu FILE > SAVE AS....
5.- Add a name that allows you to distinguish the configuration from others that you make to store in other
presets.
NOTE: if you want to store it in the connected matrix you will have to follow the steps indicated in
MODIFY A PRESET
.
- 17 -
icon.
