EN
-
MINIMUM AND MAXIMUM GAIN: allows you to set a different minimum and maximum gain for each
channel.
HOME TAB
Displays an overview of the input and output channels and the DSP modules configured on each of them.
Provides direct access to the configuration of the DSP modules of each channel by double-clicking on them.
In addition, in the central part there is direct access to other tabs (AUTOMIXER, AEC, ANS and MATRIX) and
the player/recorder.
In this tab we can edit the DSP modules that apply to each channel. For more information on DSP modules
and their editing go to section DSP MODULES FOR INPUTS/OUTS.
Panel Editor
Module
INPUT SOURCE
DSP modules of
input channels
(editable)
INPUTS TAB
It shows only the input channels at the bottom and the DSP modules associated with the selected channel
at the top. For quick access to each of the DSP modules assigned to the selected channel, use the list to
the right of this upper block.
For more information on DSP modules go to DSP MODULES FOR INPUTS/OUTS.
Name
Mute channel
Gain
Port number
Link channels
Quick access
to channels
Minimum and maximum gain
INPUT Channels
Create groups
Minimum and
maximum gain
OUTPUT Channels
Player/Recorder
- 22 -
DSP modules of
output channels
(editable)
