EN
EDIT PASSWORD
Once the USER ADMIN function for user/password access control has been enabled, the USER ADMIN
option shall only be available to the ADMIN user. The rest of the users will be able to access to change their
password after entering the credentials to connect the matrix through this menu option.
MENU BAR - HELP
ABOUT: displays the system information (software version and matrix model).
SUPPORT: gives access to a manual in English.
COMMAND CAPTURE: provides the command in hexadecimal. Open this window and modify the parameter
you want, automatically this window will show the corresponding command for that action that you can use
in an external equipment that communicates through UTP or RS232.
CHECK FOR UPDATES: function disabled. If you experience any problems, please consult the website or
contact FONESTAR's customer service.
OTHER TOOLS
RESET PRESETS TO FACTORY DEFAULTS
Shortcut to reset all presets to default settings.
RESET MATRIX TO FACTORY DEFAULTS
Shortcut to delete all configuration made on the matrix, including its network configuration.
MUTE ALL
In the top right corner there is a button
which allows all channels to be muted at the same time.
The button will turn red when the mute function is activated.
MIRRORING FUNCTION
As a security measure, the system offers the possibility of establishing a security matrix (SLAVE) that will
replace the main matrix (MASTER) in the event of failure of the latter without losing operability in any device.
The only connection requirement is that both matrices are connected to the same switch. Both the audio
sources connected to the inputs and the stages connected to the outputs can be the same if desired, as the
SLAVE matrix will remain muted until the MASTER matrix fails. Or, if you wish, you can have different devices
connected to the inputs and outputs of the SLAVE matrix.
For this function it will not be necessary to configure the SLAVE matrix as it will automatically receive the
MASTER configuration.
In order for these to work in this way, the following configuration is required:
1.- In the SLAVE matrix we will only have to configure the network configuration and connect it to the same
network as the MASTER matrix. This matrix will display the
icon.
- 16 -
