BUILT-IN PLAYER
With the USB-A to USB-A cable connected between the matrix and the computer
with the control software, the computer will be able to access the sound board
of the matrix (USB INPUT).
The matrix will be able to access the audio tracks on your computer, create
playlists and play them back.
Before using the player, you must set the sound board of the matrix as output:
1.- Double click on the player screen.
2.- In the next window click the
3.- And in the pop-up window configure the options shown:
-
SOUND CARD: speakers through which the audio will be played. Select RS SOUND CARD to play
through the matrix and in the MATRIX tab route the USB input to the desired output(s).
-
CHANNEL: channel on which the audio will be played: LEFT (left channel), STEREO (both channels)
or RIGHT (right channel).
4.- Go to the MATRIX tab and assign to the USB input all the outputs you want the audio from the player
to be heard.
Once this is set up, you can add audio tracks and create playlists. After double-clicking on the player screen,
a window with the following elements will appear:
Tracks ready to play
The currently playing track will be identified by the
If you click on one of the tracks, 2 icons will appear: to delete the recording
containing the recording
list and from the computer.
button.
Load playlist
Save playlist
Track time
in playback
Add track
. At the bottom of this screen there is a button
Open track location
Remove track
Duration of the track
Track name
Remove all tracks
icon.
- 19 -
or to access the folder
to delete all recordings from the
EN
