CONSERVATIVE: 120 ms
-
MODERATE: 256 ms
-
AGGRESIVE: 512 ms
-
ON/OFF: enables or disables the AEC module.
NOTE : use the output of the AEC as the resulting audio in the Matrix. Do not add both AEC signal and
local source signal to the matrix or the desired effect will be lost.
ANS - AUTOMATIC NOISE SUPPRESSION TAB
Displays the input and output channels and the recorder player at the bottom. And, at the top, shortcuts to
the channels, the configuration of each channel and the main parameters of the ANS system module.
Configuration
ANS
Automatic Noise Suppression (ANS) can remove audio that it detects as noise using an intelligent algorithm
that allows it to distinguish the human voice from other sounds. It treats the latter as noise and can thus
subtract noise from the original audio source.
The parameters to be configured are:
-
1-32, AUTOMIXER, USB, AEC: allows the selection of the source(s) to which to apply the ANS module.
-
LEVEL : audio attenuation of non-human voice: 6 dB, 10 dB, 15 dB or 18 dB.
-
ON/OFF : enables or disables the ANS module.
falta acceso directo a canales
INPUT Channels
cambiar imnagen
Player/Recorder
- 27 -
OUTPUT Channels
