3.- To link the wall panel to a matrix join the dots drawn next to each panel and each matrix and a line will
be created between the two. When you click on the first one, it will turn red and create a line with the
mouse pointer until you click on the second item.
4.- Double click on the panel you want to configure. In this new window you will find all the actions configured
in the order in which they will be displayed on the wall panel. In this view you can edit or delete actions
(EDIT, DELETE), change the order (using the arrows on the left of the panel) or add new options (+ ADD
MENU). For more information see the previous section on ACTIONS IN NMX-WP where the actions and
their parameters are detailed for each one of them. Press the SIMULATION button if you want to verify
the result of your configuration and press OK to finish.
Move up/down
an action
5.- Once you have configured all the NMX-WP panels created in the central panel of the window, you can
save the file by clicking on the button
6.- (ONLINE ONLY) If you have connected all the panels that you have represented in the central panel of
the window, click on the
has finished. In a new window a % bar will indicate the progress of the upload and the window will close
when the upload is complete.
(SAVE AS).
button (UPLOAD TO PANEL) and and wait a few seconds until the process
- 48 -
Panel name
IP address of the
panel
Delete an action
Edit an action
Add an action
