Dis T.1634007e
LOGIC
It defines the logical operator to activate of the outputs (relay) on the thresholds:
OR (logical sum): The outputs relating to thresholds are triggered when one or more sensors in the
area exceed its threshold. (It is the normal operation, each sensor activates the alarms at
exceeding of the set
AND(logical product): The outputs relating to thresholds, are triggered only when all the sensors in
the area exceeds its threshold.
CORR.CON (Correspondent Consecutive): The outputs relating to thresholds are triggered when two
consecutive sensors in the area exceed its threshold. The last and the first are not considered
consecutive (e.g. installation along a corridor).
CIRC.CON (Circular Consecutive): The outputs relating to thresholds are triggered when two
adjacent sensors in the area exceed its threshold. The last and the first are considered
consecutive (e.g. installation in a circle).
PARK-ITA(Only for Italy, Parking in accordance with the Italian Ministerial Decree): The outputs relating to
thresholds are triggered when two sensors belonging to the zone exceeds its threshold. This
configuration must be used if the control unit for garages must be programmed in accordance with
Ministerial Decree 02.01.1986 (point b of paragraph 3.9.3) and subsequent Ministerial Decree
03/08/2015 - D.M. 21/02/2017.
Description of the items relating to the outputs:
The description of the items: OUTPUT N, SILENCEABLE, SILENCE, HYSTER.ON, HYSTER.OFF/TIME ON,
POS LOGIC and LATCHED are identical to those of the chapter, CONFIGURE SENSORS
Then at the end of the screen, move to CONTINUE (relay output configurations relating to
THRESHOLD 1 and THRESHOLD 2). Press
outputs relating to THRESHOLD 3 and FAULT (failure). Finally, move to SAVE, to save the
configuration entered.
By pressing
the confirmation window will appear. Press
ENTER
to confirm or
to go back. If the procedure is correct, the window
ESC
warns that the operation was successful.
Then the screen returns to the CONFIGURE ZONES screen.
ZONES-DELETE (Level 2):
This item allows you to delete a ZONE or a group of ZONES from the
configuration.
The access level procedure is explained in the
After choosing, choose whether to act on a single ZONE (1
nd
a group of ZONES (2
warn you that the operation was successful.
Then the screen returns to the beginning of the CANCEL management.
By deleting a ZONE, the relay outputs configured in it will no longer be available.
ZONES-MODIFY (Level 2):
To modify a configured ZONE, press
parameters in the same way as the configuration as described in the
paragraph.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
threshold)
line) and confirming with
on the relevant item and then proceed to modify the
to continue until the configuration screen of the
again
SENSORS-DELETE
st
line) or on
the window, it will
ENTER
Pag. 30/52
ZONE
N. 1
CONFIGURED
DELETE
ZONE N.
1
FROM N.
TO N.
section.
ZONE
N. 1
DELETED
ZONES - CONFIGURE
