Dis T.1634007e
SINGLE DIGIT NUMERIC FIELD (PASSWORD ENTRY, ETC.)
By pressing
and
SCREENS 'ENABLE ...', 'DISABLE ...', 'COPY ...', 'DELETE ...', 'SETTINGS DATE & TIME'
Pressing the first time,
the next digits will be always inserted to the right of the number.
Example: to enter the number "12", press
move to the right and then press
If the number exceeds the maximum acceptable value, message will
appear "PARAMETER OUT OF RANGE".
DISPLAY – ALL OTHER SCREENS
As above, but in addition, when you press the
continue to enter additional digits.
Example: If you have entered the number "23", and then you want to change it to "25", simply press the
then press
5 times (or press
If you have already entered a single digit, pressing
field. Then, by pressing
one.
DISPLAY – INITIAL SCREENS
The unit, when powered, for 5 seconds shows the model name and the
installed firmware version.
This information shall be accessible also in the menu SettingsInfo.
For more information read the chapter Settings.
Only at first power (and only then) will be asked to choose
your language and to indicate if the battery is present. Use the
key
and
the key
to confirm the choice.
ENTER
If necessary, these choices can be changed. Please see forward
Service
Battery.
PREHEATING TIME
At each start-up, a decreasing count of 90 seconds will always start, it is
the time necessary for the control unit to start up and allow the Sensors
to stabilize.
DISPLAY – MAIN SCREEN
After the preheating time, appears the main screen that the control unit
displays in normal operation. The date is shown in the top row, the first 6
sensors (with the measured concentration and its state) and in the last
line, the battery status of charge (if installed) and presence of the mains.
PSW (PASSWORD) followed by a number, at the bottom left indicates the
current access level (eg PSW 2 indicates that Level 2 is enabled).
*
The "
" symbol (near to the date) indicates that daylight saving time is active.
The word 'SD' at the bottom right indicates that the SD-Card is inserted.
If the word 'DATA LOG' is also present, data storage is enabled (Data Logger).
Symbols used to indicate the status of the battery (if installed):
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
key, the number is displayed in the field.
key, the number is displayed in its field (deleting any existing number), and
once, then press
twice, or press
)
or
key, the value already present is deleted and replaced with the new
to scroll through the languages and pressing
to
e then
.
key, the last digit entered will be erased and you can
will display the minimum value accepted by the
Pag. 16/52
PARAMETER
OUT OF SCALE
ver.
CE424
2.0X
L I N G U A - L A N G U A G E
L A N G U E - I D I O M A
1 - > ITALIANO
2 - > ENGLISH
3 - > FRANCAIS
4 - > ESPAÑOL
PRESENCE BATTERY
1 - > NO
2 - > YES
WARM UP
90
Wait . . .
12:00
FRI
08/07/2020
1) 2 % LFL
NORM
2)10.2 ppm
AL.1
3) 300 ppm
AL.3
4) - - - -
5) - - - -
6) - - - -
PSW 2
DATA LOG SD
*
