Dis T.1634007e
NOTE: The value of a "NOT CONFIGURED" sensor is always 0.
Since the submitted values, are the word (16-bit signed), to represent decimal numbers, certain
values are multiplied by a factor determined by the number of decimal places specified in the
configuration of the sensor. If the decimal places are 0, the value is not multiplied. With a number,
multiply it by 10, with 2 digits for 100 and 3 digits for 1000.
As for the status of the sensors, the table below explains the meaning of the possible values.
Value
Description
0
Sensor in fault due to lack of signal or disabled
1
Sensor disabled
2
Sensor in normal status
3
Sensor in AL1 alarm status
4
Sensor in AL2 alarm status
5
Sensor in AL3 alarm status
6
VALUE NOT USED
7
Sensor faulty (Fault) due to excess signal (over the Full Scale)
8
Oxygen Sensor in Alarm for Oxygen Deficiency
9
Oxygen Sensor in Alarm for Excess Oxygen
100
Status unknown
255
Sensor not configured
SETTINGS-INFO
In this submenu you can view the model, the Firmware version, and the
contacts (postal address, telephone and email address). Press
go back.
PASSWORD
In this submenu you can manage the levels of access to the password
protected menus. Press
The PASSWORD Level 1 and Level 2 are factory-set to
Please note that the accessible levels are only the first two:
LEVEL 1: intended for the User
LEVEL 2: intended for the Installer or Maintenance Technician
LEVEL 3 is reserved only for the Manufacturer (Tecnocontrol).
ENABLE LEVEL:
This item allows you to enable the relative access level.
Press
on the relevant item.
ENTER
With
and
you can enter the value, with
can move from one number to another.
After entering the Password, move to OK and press
If the password entered is correct, the window will confirm the
operation. Then the screen returns to the beginning of the PASSWORD
management.
When a protected menu is selected, the request to enter the specific Password appears.
Once enabled, the number of the enabled access level appears in the lower left corner of
the main screen. In addition, the padlocks
For safety, after one hour, all access levels are automatically disabled.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
on the relevant item.
ENTER
CE424
to
20054 Segrate (MI) ITALY
PASSWORD
1 ENABLE
2 DISABLE
3 MODIFY
ENABLE
1 LEVEL 1
2 LEVEL 2
3 LEVEL 3
and
keys you
.
ENTER
LEVEL 1
ENABLE
of the level enabled disappear.
Pag. 34/52
Ver 3.0X
TECNOCONTROL srl
Via Miglioli, 47
Tel +39 02 26922890
info@tecnocontrol.it
0000
ENTER PASSWORD
LEVEL 1
0000
OK
