LOGIC INPUT – DETAILS:
To see the parameters of the already configured Logic Input, press
on the relevant item. After choosing the input, as in the configuration,
the related items and the number of the corresponding relay output are
shown. To go back, press
You can scroll through the items with
the screen, the operating and enabling status of the input are indicated.
Finally, by selecting the line with the number of the output, if different
from 0, you can view the details by pressing
The items can be scrolled with
the screen, the output silencing status is indicated.
ZONES
In this submenu it is possible to manage the ZONES, to which it is
possible to associate the Sensors.
The access level, the procedure and the items are as in the
SENSORS
section
The ZONES can be used in various ways, compatibly with the number of relay outputs available:
A - Group several sensors of the same type and use the same outputs (relays) for all of them,
configuring them only in the zone. In this case, in the individual sensors configure only the alarm
thresholds and the number of outputs all at 0. When the sensors belonging to the zone exceed the set
thresholds, they will activate the relative relay outputs, following the chosen operating logic.
B - Group different sensors but placed in the same room or on the same floor. In this case, in the
individual sensors, also configure the relay number in the outputs, while in the ZONE set in the outputs
only the numbers of the relays common to the sensors associated with that ZONE.
ZONES - ENABLE/DISABLE (Level 1):
The access level and the procedure are as described in the
DISABLE
section
These two items allow you to Enable or Disable one or more ZONES at the same time. The Disable
status is displayed on the main screen, next to the Input, with the symbol "
The disabled ZONE no longer activates the associated relay output and therefore the
devices connected to it will not be activated. This function can be used to exclude
devices that have not yet been installed or failed or removed for repair.
If the procedure is correct, a window notifies you that the operation has been successful. Then the
screen returns to the beginning of the Enable / Disable management of the ZONES.
ZONES - CONFIGURE (Level 2):
In the ZONES submenu, press
configure the ZONE.
On the screen, pressing
number of the ZONE to be configured.
Remember that the Control unit has 6 ZONES and 2 outputs (relays) for each single alarm
level, plus a fault output, for a total of 9 configurable outputs (relays) for each Zone. The fault
output, if configured, intervenes if any sensor in the Zone is faulty.
With
and
you scroll through the different items and then
pressing
only the value is selected, showing that you can change
ENTER
it.
Then with
and
you go from field to field on the same line (where applicable) and then
pressing
the change is accepted. Instead, pressing
ENTER
the previous value and the entire row is selected, showing that it is only
possible to scroll through the various items.
The various items are explained in detail below:
Description of items related to the Zone:
