APPENDIX
TECHNICAL SPECIFICATIONS
AC power supply and frequency
AC Maximum consumption
Max current delivered by the power supply
Number of detectors that can be connected
Analog Input 4 to 20 mA (Linear)
Analog Input - Load resistance
Voltage / current limits for each input.
Digital inputs for CE380UR
Connectable Remote Units (CE380UR)
Digital Output
Relay outputs
(with voltage free changeover contacts)
Nominal load of relay
(SPDT contact on each relay)
Logic Input
SD Card type accepted
Display
Optical indications
Acoustic indications
Keyboard
Backup battery (optional)
Max Charging Current from Power Supply
Battery operating time
Operating temperature/humidity (with the
batteries installed in the control unit)
Dimensions and Protection rating
Weight (without the batteries)
Weight of the internal batteries only
(1) With all the internal detectors connected and 9 relays activated.
(2) Batteries are not included. If greater autonomy is required, 2 of 12V 3Ah or 7Ah Pb batteries connected in series can also
be used, but due to the size, they must be installed in an external container.
The autonomy, with 3Ah batteries, becomes: about 3h30' with 4 detectors, 2h15' with 8 detectors.
The autonomy, with 7Ah batteries, it becomes: about 8h with 4 detectors, 5h10' with 8 detectors.
(3) Battery autonomy is calculated in the worst conditions, with all relays configured in Positive Logic and also considering a
negative coefficient due to possible effects on battery efficiency (aging, temperature, etc.).
(4) Using Metric Cable Glands (M16 and M20 Pitch ISO 1,5mm) with IP55 or higher protection degree.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
90 to 264 V AC / 47 to 63 Hz
(1)
1,6A a 110VAC / 1A at 230V AC
1,4 A a 27,6VDC
Max no. 24 of which Max 8 inside the CE424 and Max 16
inside the two CE380UR (Max 8 inside each CE380UR)
No. 8 maximum, of which no.4 factory installed, others are
expandable to 8 with expansion board ES404
RL (inside of each input) = 100 ohm
24 VDC (–10/+15%) / 100 mA (with resettable current limiter)
No. 2 RS485 ports (COM1 and COM2)
n. 2 (in each CE380UR, 8 linear 4 ÷ 20 mA analog inputs
are installed and 8 output relays can be installed, with 2
ES380UR expansion cards available on request)
No.5 factory installed, expandable to 9 with ES414
expansion card. (Available on request)
250 VAC – 2 A or 30 VDC – 2 A resistive load.
No. 1 (setting for NA or NO dry contacts)
SD e SDHC max 32Gb
SDXC formatted by PC with FAT32 (max 32Gb).
monochrome LCD graphical display with RGB backlight
No. 3 LED (Yellow, Green and Red)
Internal Buzzer
No. 18 keys with backlight
(2)
N0. 2 Pb 12VDC / 1.3Ah (connected in series)
0.75 A a 27.6VDC
(3)
about 1h30' with 4 detectors, 1h with 8 detectors.
+5 to +40 °C / 5 to 95% relative humidity
(4)
.
379 x 241 x 133 mm / IP42
about 2 Kg
(No.2x1.3Ah) about 1.2 Kg
no.1 RS485-Modbus port (COM3) with ES415 optional
expansion card. (Available on request)
Pag. 41/52
