Summary of the list of Fault and Alarm messages
STATUS
Sensor not Configured
Sensor or Zone in Fault
Sensor or Zone returned from a Fault, but
with output relay latched.
Sensor operating normally
Battery Operation - (with graphical
indication, from Full Charge up to Discharge)
Batteries Fault
Sensor or Zone or Logic Input, in Alarm 1
Sensor or Zone or Logic Input, in Alarm 2
Sensor or Zone in Alarm 3
Sensor or zone or logic input, with Alarm 3
returned to normal, but with relay output
latched.
Sensor over the Full Scale
(1) Blinking = 1sec ON / 1sec OFF / (2) Short blinking = 0,1sec ON / 1sec OFF / (3) Rapid blinking = 0,1sec ON / 0,1sec OFF
DISPLAY MESSAGE
LEVEL NOT ENABLED ACCESS DENIED
RESET DONE
SENSOR NOT CONFIGURED
OUTPUT NOT CONFIGURED
INPUT NOT CONFIGURED
ZONE NOT CONFIGURED
CONFIGURATION ERROR CHECK
PARAMETERS
OUT OF SCALE PARAMETER
INVALID DATE
WRONG PASSWORD
FIRMWARE MISSINGOR JUST PRESENT
NO SD CARD
SD CARD NOT READABLE
SD WRITE PROTECTED
CORRUPT FIRMWARE
UPDATE FAILED
ERROR MISSING OR NOT READABLE FILE
ERROR OPERATION FAILED
ATTENTION SD CARD ALMOST FULL
ATTENTION SD CARD FULL
STORAGE DATA INTERRUPTED
