RESET
The RESET item in the main menu, performs the same function as
key, reset the latched outputs to normal operation, but only if the Sensor
or Zone or Logic Input has returned from the alarm condition.
If there are active alarms, outputs configured as Silenceable (e.g. an
alarm) return to normal operating conditions only for the time of
silencing.
When performing the RESET (with key or from the menu), the display
shows the confirm message for about 3 seconds, then the previous
screen reappears automatically.
REMOTE UNITS
In this submenu you can manage the Remote Units connected to the
unit.
Below, the individual items are described in detail, with the
corresponding level password, which is indicated in brackets.
Remember that to enter values, you can use both the
and the corresponding numeric keys.
REMOTE UNITS - ENABLE / DISABLE (Level 1)
The control unit no longer monitors the sensors of the R.U. disabled, and therefore will no
longer activate the fault and alarm outputs (relays) associated with them and therefore the
devices connected to the relays will not be activated.
To Enable or Disable a R.U. press
highlighted. With
and
on a single R.U. or both.
st
The 1
line, is acting on a single R.U. Pressing
highlight the number of the R.U. Then you choose the desired number,
with
and
keys and then, pressing
nd
will appear. The 2
line, acts on both R.U. Pressing
st
will highlight the 1
R.U. number.
With
and
you can choose the number of R.U. desired, with
ond
you go from one extreme to the other and then pressing
again the confirmation window will appear.
ENTER
To confirm press
. To go back, press
ENTER
If a U.R. is not configured, a window warns that the operation is not
possible.
Then the screen returns to the choice of the R.U.
If the procedure is correct, the window warns you that the operation was
successful.
Then the screen returns to the beginning of the management of the
enabling and disabling of the R.U.
REMOTE UNITS – CONFIGURE (Level 2)
To start the configuration, press
With
or
, and then pressing
Remote Unit to configure.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
key on the relevant item
it is possible to select, if you take action
on the 1
the confirmation window
ENTER
ESC
.
on the relevant highlighted item.
ENTER
you can choose the number of
ENTER
,
RESET
REMOTE UNITS
1-ENABLE
2 DISABLE
3 CONFIGURE
4 DELETE
and
keys
5 MODIFY
6 DETAILS
ENABLE
CONCENTRATEUR N.
FROM N.
st
line, will
ENABLE
CONCENTRATEUR N.
FROM N.
nd
on the 2
line,
CONFIRM ?
YES = ENTER
NO = ESC
REMOTE UNIT
CONFIG. REM. UNIT
REM.UNIT N.
Pag. 20/52
RESET
PERFORMED
TO N.
TO N.
RMOTE UNIT
N. 1
NOT CONF.
N. 1
ENABLE
1
