Dis T.1634007e
When the control unit restarts, the automatic firmware update begins,
which lasts about 3 ÷ 5 minutes. This phase is indicated by the flashing
of the yellow LED and the message on the display.
If there is no file on the SD Card or there is a firmware version that is
previous or equal to the one already installed, the control unit will report
it and then restart without updating.
If the SD Card is not readable, the control unit will report it and then
restart normally
If the SD Card was write protected.
If the SD-Card is not inserted or is not detected, the control unit will
report it and then restart normally. Check that you have correctly
inserted the card and, if necessary, check its operation by testing
menu Service
Electric Test
At the end of the update, a message will confirm that the operation is
finished, in addition, the green LED and the buzzer will light up for 3
seconds. After that, the control unit will restart in normal operation.
If the update was not carried out correctly, the display will inform you
that the operation has failed and for 3 seconds, the red LED and the
buzzer will light up. Then it will automatically restart in normal
operation, but with the previous Firmware version.
Put Jumper JP3 back in the "OPEN" position, otherwise, at each restart, the control
unit will check if there is an update file on the SD Card.
Firmware may be incomplete. This would be reported when the
control unit restarts. In this case, try to power down and power up the
control unit and repeat the update. If the problem persists, check the
integrity of the update file by loading the previous working firmware
version. If not, contact the supplier.
COPY CONF. FROM (Level 2): This " COPY CONFIGURATION FROM" item allows you to load a
configuration (Sensors, Logic Input, Zones, RU and Outputs) on a control unit, using a file previously
saved on the SD Card. The file, named 'CE424P_CF.txt', can be created ONLY with the 'COPY
CONFIGURATION ON' (see below). This function can be used to restore a configuration on a control
unit (memory failure) or to transfer the same configuration to other control units of the same model.
By pressing
on the relevant item, the operations to be performed before starting the procedure
ENTER
will be displayed.
In the event of an error or malfunction, the control unit configuration is irretrievably
deleted. It is advisable to always fill in the
After inserting the SD Card, press
configuration or press
A wait message is displayed while copying.
If the SD Card was write protected, the control unit signals it with a
message and returns to the SD Card submenu.
If the SD card is unreadable or not formatted correctly or the file is
missing, the control unit signals it with a message and returns to the SD
Card submenu.
In the event of a Read / Write error or a corrupt file, the control unit will
report the error, then delete the current configuration and then reboot
normally to reload the previous configuration.
If the operation is successful, the control unit will report it and then
restart normally to reload the new configuration.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
SD
Card).
to start copying and updating the
ENTER
to go back
ESC
(see
Reminder Table
(See at the end of the manual).
Pag. 38/52
WAITING
UPDATE IN PROGRESS
FIRMWARE MISSING
OR JUST PRESENT
SD CARD
NOT READABLE
SD CARD
WRITE PROTECTED
SD CARD
MISSING
UPDATE
SUCCEEDED
UPDATE
FAILED
FIRMWARE
CORRUPT
COPY CONF. FORM
INSERT IN THE
CONTROL UNIT
THE SD CARD
AND PRESS ENTER
WAIT
SD CARD
WRITE PROTECTED
ERROR
MISSING OR NOT
READABLE FILE
ERROR
OPERATION FAILED
WAITING
REBOOT IN PROGRESS
