Dis T.1634007e
ZONES-DETAILS:
To see the parameters of the already configured ZONE, press
Once the ZONE has been selected, as in configuration, the items
relating to the zone and the number of relative relay outputs are shown.
You can scroll through them with
screen, the operating and enabling status of the ZONE is indicated.
Finally, scrolling to one of the lines with the number of the output, if it is
different from zero, pressing
output details (relay) are scrolled with
screen, the silence status of the output is indicated.
EVENTS
In this submenu it is possible to view the last 100 events stored by the control unit and sorted from the
most recent to the oldest.
The control unit stores the events cyclically, that is, after No.100; the oldest event is
always deleted.
EVENTS - ALARMS / FAULTS: Only those relating to Sensors, Logic
Inputs, Zones and Relay Outputs can be displayed.
EVENTS - ALL: the generic events memorized by the control unit,
including those of Presence or Absence of mains, Switching on and
Reset of the control unit.
The items are scrolled with
date, time and type of event. Events are displayed in groups on the same day starting with the most
recent. Then with the
First line:
is the date of the event, in the format dd / mm / yy (Day / Month / Year).
Each subsequent line is an event
First part on the left:
Second part on the right: this is the type of event as follows:
First letter:
S
= SENSOR
Two numbers:
State:
The LOGIC INPUTS can have 2 states:
ATT. (Active, in alarm) or DIS. (Off, returned to normal).
The OUTPUTS (relays) can have 3 states:
ATT. (Active, in alarm), DEA. (Deactivated, returned to normal) or SIL. (Alarm Silenced).
SENSORS and ZONES can have 6 states:
FLT (Fault), NORM (Normal), OVS. (Over Scale),
AL1 (Alarm 1 exceeded), AL2 (Alarm 2 exceeded) or AL3 (Alarm 3 exceeded).
Generic events, which can be viewed from the
POWER ON - the control unit has been switched on.
MAIN YES - the control unit is mains power supply, only if batteries are installed.
MAIN NO - the control unit is powered only by batteries, if installed.
RESET - Reset performed from keyboard or menu.
SERV.1 (Electrical Test performed - Service Function).
SERV.2 (Battery Test performed - Service Function).
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
and
. Then, at the end of the
displays the details. The items of the
ENTER
and
and
. Then press
and
keys you scroll through the events and days.
EVENTS - ALARMS / FAULTS:
is the time of the event, in the format hh/mm/ss (Hours/Minutes/Seconds).
indicates the object to which the event refers:
I
= LOGIC LOGICO
they are the number of the object to which the event refers.
it is the new state reached by the object that caused the event.
EVENTS - ALL
ALL
on the relevant item.
ENTER
ZONES DETAILS
ZONE N.
LOGIC
OUTPUT_1_ THRESH_1
OUPUT N.
OUTPUT_2_ THRESH_1
. At the end of the
OUPUT N.
EVENTS
1 ALARMS/FAULTS
2 ALL
on the chosen item. The screen shows the
Z
U
= ZONE
= OUTPUT (relay).
menu, can have 4 states:
Pag. 31/52
1
:
OR
:
2
:
3
