Dis T.1634007e
COPY CONF. ON (Level 2): This item "COPY CONFiguration ON" allows you to save the
configuration (Sensors, Logic Input, Zones, RU and Outputs) of the control unit on an SD-Card. The file in
text format, "CE424P_CF.txt", it can ONLY be created with this function and can be used as indicated
above in the previous function.
By pressing
on the relevant item, the operations to be performed
ENTER
before starting the procedure will be displayed.
After inserting the SD-Card, press
or press
to go back.
ESC
The operation sequence described is also valid for the COPY EVENTS ON and for DATA
LOGGING. The messages that could be displayed (WAIT, SD CARD WRITE PROTECTED ,
FILE MISSING OR NOT READABLE and ERROR OPERATION FAILED) are described above
in the previous paragraph.
COPY EVENTS ON (Level 2): This item Copy Events On allows you to save the list of the last
recorded events of the control unit on an SD Card. The file in text format, "CE424P_EV.txt", can
ONLY be created with this function.
The rest of the sequence of operation is similar to the previous function (see above).
DATA LOGGING (Level 1): This item allows you to continuously save the values read by the control
unit (Data Logger of the Sensors, of the logic input and of the Zones), these data are written every minute, in
the SD-Card, in a file in text format "DL_No.Month_No.Year.txt", which can be imported into
Microsoft Excel to analyse its content or view its progress through graphs
The No.Month and No.Year values are two numerical digits representing the month number and the
last two digits of the year, as set in the control unit date.
The word 'SD' at the bottom right indicates that the SD-Card is inserted.
When data storage is active, it is indicated on the main screen, at the bottom right, with the
word "'DATA LOG SD"
When the space in the SD-Card is almost exhausted, the control unit
signals it with a message. It is advisable to replace the SD-Card with a
new one as soon as possible. Press
When the space in the SD-Card is exhausted, data storage will be
interrupted and the control unit signals it with a message. It is
recommended to replace the SD-Card with a new one. Press
return to the normal view.
The rest of the sequence of operation is similar to the previous function (see above).
If, via PC, you delete an SD-Card that has already been used, it must be formatted, before
using it again in the control unit (FAT32 - max 32Gb).
SD-Card CAPACITY TO STORE DATA: Indicatively, it will be one based on its size: SD-
4Gb 2 months / SD-8Gb 4 months, SD-16Gb 8 months / 32Gb 16 months
If the procedure is successful, the item STOP DATA LOG. Appears on
the SD-CARD submenu screen. instead of this item.
By pressing
ENTER
on the relevant item it is possible to stop data storage.
Then the control unit will return to the previous SD-Card submenu.
ESC
Press
to return to the main screen.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
to start saving the configuration
ENTER
to return to normal view.
ESC
Pag. 39/52
COPY CONF. ON
INSERT IN THE
CONTROL UNIT
THE SD CARD
AND PRESS ENTER
(See Example
below).
ATTENTION !
SD CARD
ALMOST FULL
ATTENTION !
SD CARD FULL
to
DATA LOGGING STOPPED
SD CARD
1 UPDATE FIRMWARE
2 COPY CONF. ON
3 COPY EVENTS ON
4 COPY EVENTS ON
5 STOP DATA LOG.
DATA LOGGING
STOPPED
