Dis T.1634007e
Example: how to import the file in Microsoft Office Excel
slightly different):
1) Open Microsoft Excel ®.
2) Click on top of the "Data" field.
3) Click on the top left, in the "External Data" on the "Text".
4) Select the file "DL_NoMonth_No.Year.txt" and press on the button "Import".
5) Select in the "Original data type" field "Fixed width".
6) Press "Finish" and then on "OK".
7) Now the file will be loaded. The fields are disposed in the following way:
a) The first line contains: the date, the number of sensors, the number of logic inputs (preceded
by the letter "I") and the zone numbers (preceded by the letter "Z").
b) Below the date are listed minutes of when they have been recorded readings.
c) Below the sensors are three columns which represent the values, the unit of measurement and
status.
d) Below the logic inputs and the areas it is written the state.
e) If a device is not configured, it is indicated by the symbol "- - - -".
f) If a logic input or a zone is disabled, it is indicated by "
g) If a sensor is disabled, the value will still be recorded, but the state has indicated by "
h) If a sensor belongs to a disabled RU, its value is not recorded and it is displayed by symbol "
".
8)
The structure is repeated daily. You can scroll through the values and analyse them or view
the trend through a chart by selecting the column of the minutes and the recorded values.
DELETE SD (Level 2): This item allows you to delete all files into SD-Card (only the root files, but
not the folders, if present). E.g. to reuse a full SD-Card, without having to format it via PC.
Erasing an SD-Card already used, all files will be erased and will not be
recoverable. If there are folders into SD-Card, these and the files contained will
remain unaltered.
By pressing
on the relevant item, a short message will be
ENTER
displayed before starting the procedure.
Press
to confirm and to start deleting, or press
ENTER
At the end, a message will confirm that the operation is finished. Then
the previous SD Card submenu will reappear.
TECNOCONTROL S.r.l. - Via Miglioli, 47 20054 SEGRATE (MI) - Tel. 02. 26 92 28 90 - Fax 02. 21 33 734
CE424P User manual
®
(in other versions, the procedure may be
ESC
to go back.
Pag. 40/52
".
ALL FILES WILL BE
DELETED !
CONFIRM ?
YES = ENTER
NO = ESC
OK DELETION
SUCCEEDED
".
